Sanicubic 2 VX

Sanicubic 2 VX

The SANICUBIC 2 XL is ideal for residential buildings, commercial buildings, restaurants, schools, hotels, shopping centres.

  • 2 motors for more intensive use
  • Numerous inlets available
  • Standard equipment

CONTACT US:



€0.00

The SANICUBIC 2 XL has vortex KXV6 technology enabling 50mm diameter evacuation. In addition, the two motors enable operation in all circumstances. Its 5 inputs make it possible to connect all the sanitary facilities required. It comes with remote control and alarm as standard. Lastly it is available in single-phase and three-phase versions....

Show more

Sanicubic 2 VX
Order type Classic control box
Materials
Tank PP GF
Pump housing PA 12 GF
Motor housing PA 12 GF
Impeller PPO GF
Electrical Specifications
Voltage 230 V
Frequency 50-60 Hz
Power output P2 1400 W
Mode of operation S3 30%
Protection class IP68
Hydrolic
Max. head 13 m
Max. flow rate 40 m³/h
Ext. inlets diameter 40, 50, 100, 110, 125 mm
Discharge pipe diameter 90/110 mm
Vent diameter 75 mm
Total volume 120 L
Useable volume 26 L
ON/OFF level 165/95 mm
Alarm level 235 mm
Clearance 50 mm
Max. permissible temperature of the pumped liquid 70°C (5 min)
Type of impeller Vortex wheel
Type of activation Pneumatic
Identification & Logistic
Gross weight 101 kg
EAN Code 3308815063140
Product code CUBIC2XLVX
