Free Standing Lifting Stations (Sanicubic)

Sanicubic 1 VX

Aesthetic visual of a Sanicubic 1 VX S, single-phase, lifting station to be installed for grey/black water in the basement.

Sanicubic 1 VX

Wastewater drainage station for residential and commercial spaces. Sanicubic 1 VX is a wastewater drainage station that can be easily installed in individual houses and in commercial environments with light usage.
Installation without recessing: possibility to connect a toilet at the same level
Facilitated accessibility in case of maintenance
Vortex macerator wheel
Direct and secure access to the pump
Remote control box included
Wired alarm included
Find out more

Product details

- The Sanicubic 1 VX is a powerful wastewater removal pump designed for light commercial environments such as small restaurants and single-family homes. This pump efficiently handles wastewater from toilets, basins, baths, showers, bidets, washing machines, dishwashers, and sinks. It is easy to install with minimal construction work and features a removable motor for straightforward maintenance.

- The Sanicubic 1 VX comes with a standard 2-year warranty.

Advantages of Sanicubic 1 VX:
- Reliable Vortex Pump: Capable of managing wastewater from multiple WCs and various appliances.
- Ideal for Busy Commercial or Large Domestic Use: Suitable for demanding environments.
- High Pumping Capacity: Pumps wastewater up to 13 m vertically.
- Heat Resistant: Handles water temperatures up to 70°C (5 min max).
- Equipped with Control Panel and Alarm System: Ensures safe and efficient operation.
- Easy Maintenance: Motor can be easily removed for servicing.

Applications:
- Perfect for restaurants, hotels, shopping centers, food courts, office buildings, factories, and large facilities like warehouses and distribution centers.

Why Choose Sanicubic 1 VX?
Vortex Technology: Reduces clogging by efficiently handling larger solids, ensuring reliable operation.
- Flexible Installation: Suitable for various locations, including basements and garages.
- Multiple Inlets: Connects to multiple fixtures, offering comprehensive wastewater management. Integrated Alarm System: Provides alerts for potential issues, enhancing safety. Easy Access for Maintenance: Simplifies upkeep and reduces the need for frequent professional servicing.

FAQs:
Q1: What is the Sanicubic 1 VX used for?
A: It is a heavy-duty lift station designed for managing wastewater from multiple fixtures in both residential and commercial settings.

Q2: Can it be installed below ground level?
A: Yes, it can be installed below ground level, offering flexibility in your plumbing layout.

Q3: Is professional installation required?
A: While knowledgeable DIY enthusiasts can install it, professional installation is recommended for optimal performance and compliance with building codes. For more information, connect with our sales expert.
Technical specification

Sanicubic 1 VX

Materials

  • Shaft
  • Tank
  • Pump housing
  • Motor housing
  • Impeller
  • Shaft
  • Shaft
  • Tank
  • Tank
  • Pump housing
  • Pump housing
  • Motor housing
  • Motor housing
  • Impeller
  • Impeller
  • Shaft
  • Stainless steel
  • Tank
  • PP GF
  • Pump housing
  • PA 12 GF
  • Motor housing
  • PA 12 GF
  • Impeller
  • PPO GF

Electrical features

  • Number of motor(s)
  • Socket included
  • Voltage (V)
  • Frequency (Hz)
  • Power consumption P1 (W)
  • Power output P2 (W)
  • Revolution per minute (RPM)
  • Maximum current (A)
  • IP Rating
  • Electrical class
  • Motor insulation class
  • Mode of operation
  • Current
  • Length of cable-control box (m)
  • Number of pumps
  • Type of control box
  • Length (m)
  • Section (mm²)
  • Type of cable
  • Number of motor(s)
  • Number of motor(s)
  • Socket included
  • Socket included
  • Voltage (V)
  • Voltage (V)
  • Frequency (Hz)
  • Frequency (Hz)
  • Power consumption P1 (W)
  • Power consumption P1 (W)
  • Power output P2 (W)
  • Power output P2 (W)
  • Revolution per minute (RPM)
  • Revolution per minute (RPM)
  • Maximum current (A)
  • Maximum current (A)
  • IP Rating
  • IP Rating
  • Electrical class
  • Electrical class
  • Motor insulation class
  • Motor insulation class
  • Mode of operation
  • Mode of operation
  • Current
  • Current
  • Length of cable-control box (m)
  • Length of cable-control box (m)
  • Number of pumps
  • Number of pumps
  • Type of control box
  • Type of control box
  • Length (m)
  • Length (m)
  • Section (mm²)
  • Section (mm²)
  • Type of cable
  • Type of cable
  • Number of motor(s)
  • Single motor
  • Socket included
  • no
  • Voltage (V)
  • 220-240
  • Frequency (Hz)
  • 50-60
  • Power consumption P1 (W)
  • 2000
  • Power output P2 (W)
  • 1400
  • Revolution per minute (RPM)
  • 2800
  • Maximum current (A)
  • 8
  • IP Rating
  • IP68
  • Electrical class
  • I
  • Motor insulation class
  • F
  • Mode of operation
  • S3 15 %
  • Current
  • Single-phase
  • Length of cable-control box (m)
  • 4
  • Number of pumps
  • 1
  • Type of control box
  • Classic
  • Length (m)
  • 2,5
  • Section (mm²)
  • 1.5
  • Type of cable
  • H07 RN-F 3G

Hydraulic

  • Max. Head (m)
  • Max. flow rate (m³/h)
  • Number of inlets
  • External inlet diameter (mm)
  • Discharge diameter ext. (mm)
  • Ext. ventilation diameter (mm)
  • Total volume (L)
  • Useable volume (L)
  • ON Level (mm)
  • OFF level (mm)
  • Alarm level (mm)
  • Free passage (mm)
  • Max. temperature of the pumped liquid (5 min) (° C)
  • Type of impeller
  • Type of activation
  • Max. Head (m)
  • Max. Head (m)
  • Max. flow rate (m³/h)
  • Max. flow rate (m³/h)
  • Number of inlets
  • Number of inlets
  • External inlet diameter (mm)
  • External inlet diameter (mm)
  • Discharge diameter ext. (mm)
  • Discharge diameter ext. (mm)
  • Ext. ventilation diameter (mm)
  • Ext. ventilation diameter (mm)
  • Total volume (L)
  • Total volume (L)
  • Useable volume (L)
  • Useable volume (L)
  • ON Level (mm)
  • ON Level (mm)
  • OFF level (mm)
  • OFF level (mm)
  • Alarm level (mm)
  • Alarm level (mm)
  • Free passage (mm)
  • Free passage (mm)
  • Max. temperature of the pumped liquid (5 min) (° C)
  • Max. temperature of the pumped liquid (5 min) (° C)
  • Type of impeller
  • Type of impeller
  • Type of activation
  • Type of activation
  • Max. Head (m)
  • 13.5
  • Max. flow rate (m³/h)
  • 40
  • Number of inlets
  • 3
  • External inlet diameter (mm)
  • 40, 50, 110, 125, 100
  • Discharge diameter ext. (mm)
  • 90/110
  • Ext. ventilation diameter (mm)
  • 75
  • Total volume (L)
  • 60
  • Useable volume (L)
  • 21
  • ON Level (mm)
  • 165
  • OFF level (mm)
  • 95
  • Alarm level (mm)
  • 235
  • Free passage (mm)
  • 50
  • Max. temperature of the pumped liquid (5 min) (° C)
  • 70°C
  • Type of impeller
  • vortex
  • Type of activation
  • pneumatic

Logistics

  • Gross weight (kg)
  • Gross weight (kg)
  • Gross weight (kg)
  • Gross weight (kg)
  • 35

General description

  • EAN code
  • EAN code
  • EAN code
  • EAN code
  • 3308815077611
